HTN plastic 7pin bending spring loaded pogo pin magnetic connector with PCB

The right angle magnetic connector is a specialized interconnect solution designed for applications requiring reliable, high-cycle connections with magnetic alignment.

Key Features:

1.7-Pin Configuration

Provides multiple conductive paths for power, data, or signal transmission.

Common in charging, data transfer, or modular electronic connections.

2.Spring-Loaded Pogo Pins

Ensures consistent contact pressure and compensates for minor misalignments.

Enhances durability (typically rated for thousands of insertion cycles).

3.Magnetic Coupling

Uses embedded magnets for secure, quick attachment/detachment.

Self-aligning for user convenience.

4.HTN Plastic Housing

High-Temperature Nylon (HTN) offers excellent mechanical strength, heat resistance, and durability.

Lightweight yet robust, suitable for industrial or consumer electronics.

5.Bending Design (Flexible/Adjustable)

May allow angular flexibility or strain relief to prevent cable damage.

Useful in wearable devices, rotating joints, or tight-space applications.

Typical Applications:

Modular Electronics (drones, robotics, detachable modules).

Medical Devices (wearable sensors, quick-disconnect equipment).

Consumer Gadgets (magnetic charging cables, smartwatch docks).

Industrial Equipment (waterproof/durable connectors for harsh environments) ect.

Advantages:

✔ Reliable Connection – Spring pins maintain contact even under vibration.

✔ User-Friendly – Magnetic snap-in simplifies blind mating.

✔ Space-Saving – Compact 7-pin design fits small form factors.

✔ Durable – HTN plastic resists wear, heat, and chemicals

Magnetic attraction force between the male and female docking interfaces of 7pin right angle magneti connector is >450 grams (g),, which is critical for stable connections in high-vibration or portable applications. The male female magnetic connector is use N52-grade neodymium magnets, N52 is the highest grade of commercially available neodymium magnets,it is high-performance permanent.

7pin magnetic connectors parameter:

7pin male bending magnetic connectors:

7pin female bending magnetic connectors:

Recommended pcb layout:

Layout tolerance:±0.05mm
